Motu 8D USB

The 8D provides universal connectivity to your Mac or PC through USB or AVB/TSN. Renowned drivers deliver industry-leading ultra-low latency and proven, rock solid performance.

High-performance computer connectivity
New, optimized drivers for both Mac and PC deliver ultra-low latency performance. With a high-performance DAW such as Digital Performer, the 8D delivers an astonishing round trip latency (RTL) of 1.70 ms (milliseconds) on OS X and 1.71 ms on Windows over USB (at 96 kHz with a 32-sample host buffer).

DSP mixing and effects processing
The 8D's 48-input digital mixer delivers 7 stereo aux busses, 3 groups, access to 64 network inputs, and DSP effects, including classic reverb, EQ modeled after British analog console EQs and compression modeled after the legendary LA-2A compressor. If you know your way around a large-format mixing console, you'll feel right at home. With 32-bit floating point processing, the 8D's DSP engine delivers virtually unlimited headroom and the utmost in sound quality.

Web app control
The software that you use to control the 8D doesn't reside on your hard drive. It's a web app served from the hardware itself. This means you can control the 8D'son-board DSP, mixing, and device settings from the web app software running in your favorite web browser on the computer, or even a tablet or smartphone on the same Wi-Fi network as your computer.

Audio analysis tools
Analyze and scope your audio with advanced diagnostic tools, including a full-screen real-time FFT display, spectrogram "water- fall" display, full-featured oscilloscope, X-Y plot and phase analyzer.

AudioDesk
Includes AudioDesk workstation software for Mac and Windows with 24-bit recording, sample-accurate editing and 32-bit mixing and mastering

Χαρακτηριστικά:

• Connectivity: USB, Ethernet
• Form Factor: Desktop
• Digital Inputs: 2 x Coax (S/PDIF), 2 x XLR (AES/EBU)
• Digital Outputs: 2 x Coax (S/PDIF), 2 x XLR (AES/EBU)
• Data I/O: 1 x Ethernet (AVB)
• Headphones: 1 x 1/4"
• USB: 1 x Type B
• Clock I/O: In/Out
