Novation Summit 16 Voice Analog

Summit’s digital New Oxford Oscillators offer subtractive, FM and wavetable synthesis, and feed into genuine analogue dual filters, distortion and VCAs. The multitimbral engine enables merging and combining of two complete and independent patches, while up to 16 simultaneous voices deliver enough harmonic depth for even the richest of pads.

The best sounding synthesiser Novation has ever made

Summit doubles the power of Peak’s digital New Oxford Oscillators up to 16 voices and two parts, and adds a wealth of new features and a premium-quality five-octave keyboard. A synth much greater than the sum of its parts, it gives the serious producer or performer everything they need to design and play stunning basses, leads, arps, pads, effects and beyond.

Totally tactile sound design

Summit takes Peak’s architecture and workflow to new heights, with a swathe of extra front panel controls for hands-on wrangling of FM, effects, LFOs and more; dual filters with six LP/HP/BP combinations; audio input for processing external sources with the onboard effects; and auxiliary audio outputs.

Analogue where it matters

The true stereo analogue signal path comprises dual analogue multimode filters, analogue VCAs and three stages of analogue distortion – pre- and post-filter, and post-VCA. With roots in the legendary OSCar, via Bass Station II, Summit’s analogue credentials are truly impressive.

Features:

Synth Engine

• 16 note polyphony (dependent on voices used per note)
• 2-part-timbral
• Layered, Split, Dual Bi-Timbral Modes
• 5 Voice Modes - Mono, MonoLG, Mono2, Poly, Poly2

Waveforms Include

• Sine, tri, sawtooth, square / pulse, plus 43 wavetables of 5 waveforms per row

Modulation

• 16 modulation slots per patch
• 2 sources per destination per slot

Product Hardware Specifications

• 50 control knobs
• 8 45mm sliders
• 1 volume knob
• 1 data encoder knob
• Rubberised knob caps with spun metal discs
• 55 function buttons
• 2 Animate buttons plus hold button
• OLED display
• Kensington Lock
• Power switch
• IEC power supply connector
• USB socket for system (MIDI comms only, no bus power)
• MIDI In / Out / Thru
• 2 1/4" jack sockets for continuous or switched pedals
• 1 3.5mm jack socket for CV in
• 2 1/4" jack sockets for left and right outputs
• 2 1/4" jack sockets for left and right auxiliary outputs
• 2 1/4" jack sockets for left and right inputs
• 1/4" jack socket for headphone output
• Metal chassis with American walnut wooden end cheeks
